Key Features
Notification Be notified of problems ensuring crucial situations are dealt with in a timely
Scheduling Customize shutdown and reboot of connected equipment and UPS
Data Logging Identify problematic trends before they escalate or export logs for analysis
Event Logging Pinpoint timing and sequence of events leading up
USB Ports Two port available with Wi-Fi Device Compatible
Temperature & Humidity (Optional) Monitoring Monitor temperature or temperature and humidity and take appropriate action when needed to ensure the best possible performance from your UPS
Optional Dry Contact IO Accessory Support Monitor external triggers and initiate actions or external devices
Additional Protocol Interface (4-wire Modbus RTU) Supports device communication on a Modbus serial line using the RTU. This mode has greater character density.
Technical Specifications
| Height | 3.81 cm |
|---|---|
| Width | 12.1 cm |
| Depth | 10.8 cm |
| Net weight | 0.14 kg |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| Standards | EN 55022 class A FCC part 15 class A ICES-003 |
|---|---|
| Product certifications | AS/NZS 3548 (C-Tick) class A GOST VCCI class A |
| Ambient air temperature for operation | -5…45 °C |
|---|---|
| Operating altitude | 0...10000 ft |
| Relative humidity | 0…95 % non-condensing |
| Ambient air temperature for storage | -15…65 °C |
| Storage altitude | 0.00…15240.00 m |
| Storage Relative Humidity | 0…95 % |
| Authentication | Radius |
|---|
| Package 1 Weight | 0.91 kg |
|---|---|
| Package 1 Height | 5.1 cm |
| Package 1 width | 23.5 cm |
| Package 1 Length | 15.9 cm |
| Warranty | 2 years repair or replace |
|---|
