Technical Specifications
| Main Input Voltage | 400 V 3 phases |
|---|---|
| Other Input Voltage | 380 V 415 V |
| Main Output Voltage | 400 V 3 phases |
| Other Output Voltage | 380 V 415 V |
| rated power in W | 100000 W |
| rated power in VA | 100000 VA |
| provided equipment | Dust filter Installation guide Start-up service |
| colour | White (RAL 9003) |
|---|---|
| height | 91.5 cm |
| width | 36 cm |
| depth | 85 cm |
| net weight | 145 kg |
| USB compatible | Yes |
| maximum input current | 177 A |
|---|---|
| max short time withstand current | 10 kA |
| input harmonic distortion | Less than 3 % for full load |
| load power factor | 0.5 leading to 0.5 lagging |
| Input Power Factor at Full Load | 0.99 |
| input voltage limits | 342...477 V |
| number of input connectors | 1 hard wire 5-wire (3P + N + E) |
| network frequency | 40...70 Hz |
| Maximum configurable power in VA | 100000 VA |
|---|---|
| Maximum configurable power in W | 100000 W |
| output frequency | 50 Hz sync to mains 60 Hz sync to mains |
| harmonic distortion | Less than 3 % |
| output harmonic distortion | < 3% linear load and < 5% non-linear load |
| output overload operation | 10 minutes at 125% and 60 seconds at 150% |
| UPS type | Double conversion online |
| Wave type | Sine wave |
| bypass type | Built-in static bypass |
| crest factor | 3 : 1 |
| standards | EN/IEC 62040-1 IEC 62040-2 IEC 62040-3 |
|---|
| ambient air temperature for operation | 0…40 °C |
|---|---|
| relative humidity | 0…95 % non-condensing |
| operating altitude | 0...4921 ft |
| ambient air temperature for storage | -25…55 °C |
| storage Relative Humidity | 0…95 % Non-condensing |
| storage altitude | 0.00…15240.00 m |
| acoustic level | 65 dBA |
| heat dissipation | 18767 Btu/h |
| IP degree of protection | IP20 |
| battery type | External battery system |
|---|---|
| number of battery filled slots | 0 |
| number of battery free slots | 0 |
| alarm | Audible and visible alarms prioritized by severity |
|---|---|
| control panel | Touch screen LCD user interface |
| free slots | 1 |
| Package 1 Weight | 169 kg |
|---|---|
| Package 1 Height | 114 cm |
| Package 1 width | 47.5 cm |
| Package 1 Length | 96.5 cm |
| Warranty | 1 year on-site repair or replace with factory authorized Start-Up |
|---|
