Technical Specifications
| Main Input Voltage | 400 V 3 phases |
|---|---|
| Other Input Voltage | 380 V 415 V |
| Main Output Voltage | 400 V 3 phases |
| Other Output Voltage | 380 V 415 V |
| rated power in W | 120000 W |
| rated power in VA | 120000 VA |
| provided equipment | Dust filter Installation guide Start-up service |
| colour | White (RAL 9003) |
|---|---|
| height | 130 cm |
| width | 50 cm |
| depth | 85 cm |
| net weight | 193 kg |
| USB compatible | Yes |
| maximum input current | 207 A |
|---|---|
| max short time withstand current | 10 kA |
| input harmonic distortion | Less than 3 % for full load |
| load power factor | 0.5 leading to 0.5 lagging without derating |
| Input Power Factor at Full Load | 0.99 |
| input voltage limits | 342...477 V |
| network frequency | 40...70 Hz |
| Maximum configurable power in VA | 120000 VA |
|---|---|
| Maximum configurable power in W | 120000 W |
| output frequency | 50 Hz sync to mains 60 Hz sync to mains |
| harmonic distortion | Less than 3 % |
| output harmonic distortion | < 3% linear load and < 5% non-linear load |
| output overload operation | 10 minutes at 125% and 60 seconds at 150% |
| output voltage tolerance | +/- 1 % |
| UPS type | Double conversion online |
| Wave type | Sine wave |
| standards | EN/IEC 62040-1 IEC 62040-2 IEC 62040-3 |
|---|
| ambient air temperature for operation | 0…40 °C |
|---|---|
| relative humidity | 0…95 % non-condensing |
| operating altitude | 0...4921 ft |
| ambient air temperature for storage | -25…55 °C |
| storage Relative Humidity | Non-condensing 0…95 % |
| storage altitude | 0.00…15240.00 m |
| acoustic level | 72 dBA |
| heat dissipation | 20473 Btu/h |
| IP degree of protection | IP20 |
| battery type | External battery system |
|---|---|
| number of battery filled slots | 0 |
| number of battery free slots | 0 |
| alarm | Audible and visible alarms prioritized by severity |
|---|---|
| control panel | Touch screen LCD user interface |
| Package 1 Weight | 223 kg |
|---|---|
| Package 1 Height | 150 cm |
| Package 1 width | 62.5 cm |
| Package 1 Length | 97.5 cm |
| Warranty | 1 year on-site repair or replace with factory authorized Start-Up |
|---|
